SPL MixDream

The MixDream is a cascadable, 16-in-2 analog summing device with switchable inserts and mastering section. Exclusively built with discrete Class-A technology based on a 60V rail guarantees an extremely high slew rate, a low noise level of -97dBu (A-weighted, all channels active) and a dynamic range of over 125dB. Thus the MixDream easily exceeds the level of performance of the best analog consoles.

Key features:

• High-grade analog summing on just 2U rack space
• Sophisticated, active Class A/60V stages for analog summing in the quality of the best consoles
• 16 balanced inserts allow for integrated analog effects with individual & overall hard bypass relays
• Reduction of A/D conversions (14 A/D conversions can be spared with all inserts connected). All analog tracks can be summed before A/D conversion
• Channel adjustments and automation (level, panorama etc.) remain controlled from the DAW so the user loses no digital efficiency
• Lower DAW processor utilization rates
• The most efficient possible re-sampling of individual tracks with latency free monitoring
• Surround capable (from up to 3 MixDream units)
• Channel capacity expandable through linked units
• Sensitive & transparent stereo expansion control
• Analog peak limiter for impressive loudness
• Master inserts & switchable output transformers from Lundahl
• Optimized signal paths, all switching functions via relays
• Proprietary differential amplifiers for each input
• Discrete, exceptionally low-noise power supply
• Adjustable master insert level
• Stereo expansion switch
• Analog peak limiter
• Adjustable outputs with in/out switching of Lundahl transformers
